3. Install the front bezel. “Installing the front bezel” on page 43.
4. Install the server cover. Align the rail guides on the cover with the rails on the chassis and slide the cover
to the front of the server until it snaps into position. Then, install two screws to secure the cover to the
server.
Figure 95. Installing the server cover
5. Reconnect all the external cables.
Attention: To avoid component damage, connect the power cords last.
6. Update the server configuration.
• Download and install the latest device drivers:
http://www.lenovo.com/drivers
• Update the BIOS configuration: “Using the Setup Utility program” on page 25
• Update the RAID configuration: “Configuring RAID” on page 33
• Update your system firmware: Chapter 2 “Server setup road map” on page 5
Chapter 5. Replacing hardware 97
