• Update the BIOS on your server only if the newer BIOS version specifically solves a problem you have. We
do not recommend BIOS updates for servers that do not need them. You can view the updated
information for the new BIOS version in the installation instructions for the BIOS update utility program.
• Downgrading the BIOS to an earlier version is not recommended and might not be supported. An earlier
BIOS version might not support the latest system configurations.
• If the power to your server is interrupted while the POST and BIOS are being updated, your server might
not restart properly. Ensure that you perform the BIOS update procedure in an environment with a steady
power supply. Besides, ensure that your server can restart successfully without encountering hardware
problems.
• If you have updated the BIOS firmware, all the BIOS settings become the default settings of the updated
BIOS version. You need to check and reconfigure the BIOS settings for your specific needs. You also can
record your specific BIOS settings before updating the BIOS for an easier reconfiguration in the new BIOS
version.
To update (flash) the BIOS, do the following:
1. Go to
http://www.lenovo.com/drivers and follow the instructions on the Web page to locate the BIOS
update package.
2. Download the BIOS update package and the installation instructions in a TXT file.
3. Print the TXT file that contains the installation instructions and follow the instructions to update (flash)
the BIOS.
4. After the BIOS update process is completed, check and reconfigure the BIOS settings for your specific
needs based on your note or refer to “Using the Setup Utility program” on page 25.
Recovering from a BIOS update failure
If the power to your server is interrupted while the POST and BIOS is being updated, your server might not
restart properly. If this happens, use the Clear CMOS jumper to recover BIOS settings. For detailed
procedure, see “System board jumper” on page 22.
Note: If you cannot recover the BIOS, the BIOS read-only memory (ROM) might get damaged. You might
need to replace the system board. Contact the Lenovo Customer Support Center.
Using the ThinkServer EasyStartup program
The ThinkServer EasyStartup program simplifies the process of configuring RAID and installing supported
operating systems and device drivers on your server.
The ISO image for the ThinkServer EasyStartup program is available at the Lenovo Support Web site. To
download the ISO image and burn it into a disc or a USB flash drive, do the following:
1. Go to
http://www.lenovo.com/support and follow the instructions on the Web page to locate the
ThinkServer EasyStartup program.
2. Download the ISO package for the ThinkServer EasyStartup program. The ISO package contains the
ISO image and a utility for burning the ISO image into a USB flash drive.
3. Download the readme file and read it carefully. The readme file contains important information about the
program.
4. Do one of the following:
• Use an optical drive and any CD/DVD burning software to create a bootable disc with the ISO image.
• Use an empty USB flash drive and the utility in the ISO package to create a bootable USB flash drive
with the ISO image.
Chapter 4. Configuring the server 31

Lenovo ThinkServer TS150 Specifications

General

Bus type	DMI3
Scalability	1S
Processor cache	8 MB
Processor cores	4
Processor model	E3-1225V5
System bus rate	8 GT/s
Processor series	Intel Xeon E3-1200 v5
Processor socket	LGA 1151 (Socket H4)
Processor codename	Skylake
Execute Disable Bit	Yes
Processor frequency	3.3 GHz
Processor cache type	Smart Cache
Processor lithography	14 nm
Processor manufacturer	Intel
Processor package size	37.5 x 37.5 mm
Processor boost frequency	3.7 GHz
Processor operating modes	64-bit
PCI Express configurations	1x16, 1x8+2x4, 2x8
Supported instruction sets	AVX 2.0, SSE4.1, SSE4.2
Thermal Design Power (TDP)	80 W
Number of processors installed	1
Maximum number of PCI Express lanes	16
Memory types supported by processor	DDR3L-SDRAM, DDR4-SDRAM
Memory voltage supported by processor	1.35 V
Memory channels supported by processor	Dual
Memory clock speeds supported by processor	1333, 1600, 1866, 2133 MHz
Memory bandwidth supported by processor (max)	34.1 GB/s
Maximum internal memory supported by processor	64 GB
HDD size	3.5 \
RAID levels	0, 1, 5, 10
HDD interface	Serial ATA
Optical drive type	DVD-ROM
Total storage capacity	2000 GB
Maximum storage capacity	24 TB
Number of HDDs installed	2
Internal memory	8 GB
Memory clock speed	2133 MHz
Internal memory type	DDR4-SDRAM
Memory layout (slots x size)	1 x 8 GB
On-board graphics card ID	0x191D
On-board graphics card model	Intel® HD Graphics P530
On-board graphics card family	Intel® HD Graphics
Maximum on-board graphics card memory	1.7 GB
On-board graphics card OpenGL version	4.4
On-board graphics card base frequency	400 MHz
On-board graphics card DirectX version	12.0
On-board graphics card dynamic frequency (max)	1150 MHz
Number of displays supported (on-board graphics)	3
Cabling technology	10/100/1000Base-T(X)
Ethernet interface type	Gigabit Ethernet
USB 2.0 ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	8
PCI Express slots version	3.0
Operating altitude	0 - 3048 m
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	10 - 35 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	8 - 80 %
Power supply	400 W
Power supply input frequency	50 - 60 Hz
Redundant power supply (RPS) support	-
Chassis type	Tower
Operating system installed	Windows Server 2012 Foundation
Compatible operating systems	Windows Server 2012/2012 R2, Red Hat Enterprise Linux, SUSE Linux 11/12, Windows 10, Canonical Ubuntu 14.04, VMware vSphere 2015
Processor ARK ID	88168
Intel Secure Key Technology version	1.00
Intel® Hyper Threading Technology (Intel® HT Technology)	No

Weight and Dimensions

Depth	431 mm
Width	175 mm
Height	375 mm
Weight	12500 g
