Processor
Implementation
Memory
Graphics
Media reader
SATA disk(s)
S ATA DV D ±RW
SATA controller
Chipset
Front ports
Rear ports
IEEE 1394 adptr
Audio
Speaker
Ethernet
Security chip
Keyboard
Mouse
Power supply
Cooling
Rack mount
Intel Core™ i3 Processor i3-530 or i3-540 with dual-core,
Intel 64, Hyper-Threading Technology, Virtualization Technology,
integrated 1333MHz dual-channel DDR3 memory controller,
and 4MB cache or
Intel Core i5 Processor i5-650 or i5-660 with dual-core,
Intel 64, Hyper-Threading Technology,
Turbo Boost Technology, Virtualization Technology, TXT,
integrated 1333MHz dual-channel DDR3 memory controller,
and 4MB cache
Processor in LGA1156 socket, up to one processor
2GB or 4GB std, 8GB max, UDIMM,
PC3-10600 1333MHz DDR3,
Non-ECC,
four 240-pin DIMM sockets
Some: Intel HD Graphics in processor,
one analog VGA DB-15 connector and one DisplayPort™
connector on rear, supports dual independent display
Some: NVIDIA
®
Quadro
®
FX 580, PCIe x16 adapter, 512MB,
two DisplayPort, one dual-link DVI-I*, 40W
Some: NVIDIA Quadro FX 1800, PCIe x16 adapter,
768MB, two DisplayPort, one dual-link DVI-I*, 59W
* Only two display connectors are active at a time
None
250GB or 500GB, SATA 3.0Gb/s, 7200 rpm, 3.5"
Super Multi-Burner DL DVD±RW SATA 1.5Gb/s Drive
Serial ATA, SATA 3.0Gb/s, integrated in chipset, RAID 0, 1 support,
two SATA connectors for disks, two SATA connectors for opticals
Intel 3450 Chipset,
Platform Controller Hub (PCH) for PCI, ethernet, and USB,
SMSC
®
SCH5147 Super I/O
Two USB 2.0, microphone (3.5mm), headphone (3.5mm)
Six USB 2.0, serial (9-pin), ethernet (RJ-45),
three analog audio ports (line-in, line-out, mic-in)
Intel HD model(s): one analog VGA DB-15 connector, one DisplayPort connector
None
High Defi nition (HD) Audio, Realtek
®
ALC662 codec
Internal speaker for business audio
One gigabit ethernet on planar, Intel 82578DM
STMicroelectronics ST19NP18 Trusted Platform Module (TPM), TCG 1.2-compliant
Preferred Pro USB Keyboard (USB connector), 104-key, black, Lenovo
®
logo
Optical Wheel Mouse (USB connector), black, Lenovo logo
280 watts with variable speed fan, autosensing, 85% PSU,
80 PLUS
®
Bronze qualifi ed
4 fans (power supply, CPU, rear, front)
Rack shelf support
4222-66U 4x5 i3-530 2.93 2 1x2GB
1333MHz
No 1x250GB
2
3.5" No DVD±RW No Intel HD ES50 Pro64 No Aug 10
4222-67U 4x5 i3-540 3.06 2 2x2GB
1333MHz
No 1x500GB
3.5" No DVD±RW No FX580 ES50 Pro64 No Aug 10
4222-68U 4x5 i5-650 3.20 2 2x2GB
1333MHz
No 1x500GB
3.5" No DVD±RW No FX1800 ES50 Pro64 No Aug 10
4222-69U 4x5 i5-660 3.33 2 2x2GB
1333MHz
No 1x500GB
3.5" No DVD±RW No Intel HD ES50 Pro64 No Aug 10
ThinkStation
®
E20 (4222) - TopSeller (Windows 7) - Aug 2010 - withdrawn
GHz Processor Disk(s)
SATA
optical
Graphics
adapter(s)
Global
Avail
date
ECC
memory
Slot x
bay
Disk
size
Personal Systems Reference (PSREF)
ENERGY
STAR 5.0
See footnotes for important warranty information
US models announced August 3, 2010
US models withdrawn effective October 2010 or January, February, A
ugust 2011
© Leno
vo
(CAD3-1) August 2011
Win7
preload
Memory
DIMMs
LIMITED WARRANTY
1
➫ 3-year parts and labor
➫ Customer Replaceable Unit (CRU)
parts only (with limited onsite service
for selected parts
3
, 8 am - 5 pm,
Mon - Fri coverage excluding holidays,
next business day response time)
➫ ThinkPlus
™ services available; see
http://lenovo.com/thinkplus/warranty
• Onsite service upgrade options
(in eligible locations)
7
• Post warranty maintenance
services
➫ 24 hour x 7 day
14
toll-free support
during the warranty period
1
via 800-426-7378
Type-
model
Memory
speed
GREENGUARD
®
certifi ed
RoHS-compliant
ENERGY STAR
®
5.0-compliant
EPEAT™ Gold rating
Supports ThinkVantage
®
technologies
• Raven black color; metal case
• 6.9"W x 17.0"D x 16.7"H (with handle)
• 175mm W x 431mm D x 425mm H
• 24.7 lb (11.2kg) max confi guration
• 32-liter
• Removable handle on top front
• Toolless side cover removal
• Toolless disk and optical drive removal
• Toolless adapter retention
• Illuminated front icons
• Recessed power button
Slot 1: half-length, full-height, PCIe 2.0 x16
(75w max)
Slot 2: half-length, full-height, PCIe 2.0 x1
Slot 3: half-length, full-height, 32-bit PCI 2.3
Slot 4: half-length, full-height, 32-bit PCI 2.3
Tower
Bay ① 5.25", 1.6" high, access, std optical
Bay ② 5.25", 1.6" high, access, open
Bay ③ 3.5", 1" high, access, open (media reader)
Bay ④ 3.5", 1" high, internal, std disk
Bay ⑤ 3.5", 1" high, internal, opt disk
SECURITY
• Security chip (see information on left)
• Padlock loop (in rear for opt padlock;
padlock prohibits side cover removal)
• Security slot (in rear for optional
Kensington
®
Microsaver
®
cable;
prohibits side cover removal)
• Power-on password
• Administrator password
• Boot sequence control
• Boot without keyboard, mouse
• Serial port I/O control
• USB port disablement (front or all)
Preloaded operating system
20
- Genuine Windows
®
7
Professional 64
Preloaded applications
5
(only some
listed)
• Rescue and Recovery™
• ThinkVantage Toolbox
• Norton™ Internet Security
(30 days of virus defi nitions)
• Adobe
®
Reader
®
• Adobe Flash
®
Player
• Microsoft Offi ce 2010 preloaded;
purchase product key to activate
• Corel DVD MovieFactory
®
(DVD±RW)
Cores
Accessories
1GB PC3-10600 DDR3 Non-ECC UDIMM 57Y4389
2GB PC3-10600 DDR3 Non-ECC UDIMM 57Y4390
250GB SATA 3.0Gb/s Disk (7200 rpm) 41N3015
500GB SATA 3.0Gb/s Disk (7200 rpm) 43R1990
1TB SATA 3.0Gb/s Disk (7200 rpm) 45J7918
Blu-ray™ Burner SATA 1.5Gb/s 45K1675
NVIDIA Quadro 256MB NVS 295 45K1669
NVIDIA Quadro 512MB NVS 450 57Y4398
More accessories on O-CAD sheet
Other accessories at lenovo.com/accessories
• Faster, more effi cient architecture with the latest Intel® workstation technology
• True workstation-level performance at incredibly low price point
• High Reliability with Independent Software Vendors (ISV) certifi ed applications and ECC memory support
• These small and medium business (SMB) models are part of the US TopSeller
™ Program
• These models have a 3-year limited warranty
1
• These systems are Microsoft
®
Offi ce 2010 Product Key Ready (O10PKR)
Pre-conf
RAID
②
optical
disk
⑤
③
Diskette
or Media
reader
