Lenovo ThinkStation E20 - Page 5

Processor
Implementation
Memory
Graphics
Media reader
SATA disk(s)
S ATA DV D ±RW
SATA controller
Chipset
Front ports
Rear ports
IEEE 1394 adptr
Audio
Speaker
Ethernet
Security chip
Keyboard
Mouse
Power supply
Cooling
Rack mount
Intel Core™ i5 Processor i5-650 with dual-core,
Intel 64, Hyper-Threading Technology,
Turbo Boost Technology, Virtualization Technology, TXT,
integrated 1333MHz dual-channel DDR3 memory controller,
and 4MB cache
Processor in LGA1156 socket, up to one processor
2GB std, 8GB max, UDIMM,
PC3-10600 1333MHz DDR3,
Non-ECC, four 240-pin DIMM sockets
Intel HD Graphics in processor,
one analog VGA DB-15 connector and one DisplayPort™
connector on rear, supports dual independent display
25-in-1 media reader, internal USB 2.0
250GB, SATA 3.0Gb/s, 7200 rpm, 3.5"
Super Multi-Burner DL DVD±RW SATA 1.5Gb/s Drive
Serial ATA, SATA 3.0Gb/s, integrated in chipset, RAID 0, 1 support,
two SATA connectors for disks, two SATA connectors for opticals
Intel 3450 Chipset,
Platform Controller Hub (PCH) for PCI, ethernet, and USB,
SMSC
®
SCH5147 Super I/O
Two USB 2.0, microphone (3.5mm), headphone (3.5mm)
Six USB 2.0, serial (9-pin), ethernet (RJ-45),
three analog audio ports (line-in, line-out, mic-in),
one analog VGA DB-15 connector, one DisplayPort connector
None
High Defi nition (HD) Audio, Realtek
®
ALC662 codec
Internal speaker for business audio
One gigabit ethernet on planar, Intel 82578DM
STMicroelectronics ST19NP18 Trusted Platform Module (TPM), TCG 1.2-compliant
Preferred Pro USB Keyboard (USB connector), 104-key, black, Lenovo
®
logo
Optical Wheel Mouse (USB connector), black, Lenovo logo
280 watts with variable speed fan, autosensing, 85% PSU,
80 PLUS
®
Bronze qualifi ed
4 fans (power supply, CPU, rear, front)
Rack shelf support
4222-81U 4x5 i5-650 3.20 2 1x2GB 1333MHz No 1x250GB
2
3.5" No DVD±RW Media Intel HD ES50 Pro64 No Oct 10
ThinkStation
®
E20 (4222) - TopSeller (Windows 7) - Oct 2010 - withdrawn
GHz Processor Disk(s)
SATA
optical
Graphics
adapter(s)
Global
Avail
date
ECC
memory
Slot x
bay
Disk
size
Personal Systems Reference (PSREF)
ENERGY
STAR 5.0
See footnotes for important warranty information
US model announced October 12, 2010
US model withdrawn effective A
ugust 2011
© Leno
vo
(CAD4-1) August 2011
Win7
preload
Memory
DIMMs
LIMITED WARRANTY
1
➫ 3-year parts and labor
➫ Customer Replaceable Unit (CRU)
parts only (with limited onsite service
for selected parts
3
, 8 am - 5 pm,
Mon - Fri coverage excluding holidays,
next business day response time)
➫ ThinkPlus
™ services available; see
http://lenovo.com/thinkplus/warranty
• Onsite service upgrade options
(in eligible locations)
7
• Post warranty maintenance
services
➫ 24 hour x 7 day
14
toll-free support
during the warranty period
1
via 800-426-7378
Type-
model
Memory
speed
GREENGUARD
®
certifi ed
RoHS-compliant
ENERGY STAR
®
5.0-compliant
EPEAT™ Gold rating
Supports ThinkVantage
®
technologies
• Raven black color; metal case
• 6.9"W x 17.0"D x 16.7"H (with handle)
• 175mm W x 431mm D x 425mm H
• 24.7 lb (11.2kg) max confi guration
• 32-liter
• Removable handle on top front
• Toolless side cover removal
• Toolless disk and optical drive removal
• Toolless adapter retention
• Illuminated front icons
• Recessed power button
Slot 1: half-length, full-height, PCIe 2.0 x16 (75w max)
Slot 2: half-length, full-height, PCIe 2.0 x1
Slot 3: half-length, full-height, 32-bit PCI 2.3
Slot 4: half-length, full-height, 32-bit PCI 2.3
Tower
Bay ① 5.25", 1.6" high, access, std optical
Bay ② 5.25", 1.6" high, access, open
Bay ③ 3.5", 1" high, access, media reader
Bay ④ 3.5", 1" high, internal, std disk
Bay ⑤ 3.5", 1" high, internal, opt disk
SECURITY
• Security chip (see information on left)
• Padlock loop (in rear for opt padlock;
padlock prohibits side cover removal)
• Security slot (in rear for optional
Kensington
®
Microsaver
®
cable;
prohibits side cover removal)
• Power-on password
• Administrator password
• Boot sequence control
• Boot without keyboard, mouse
• Serial port I/O control
• USB port disablement (front or all)
Preloaded operating system
20
- Genuine Windows
®
7
Professional 64
Preloaded applications
5
(only some
listed)
• Rescue and Recovery™
• ThinkVantage Toolbox
• Norton™ Internet Security
(30 days of virus defi nitions)
• Adobe
®
Reader
®
• Adobe Flash
®
Player
• Microsoft Offi ce 2010 preloaded;
purchase product key to activate
• Corel DVD MovieFactory
®
(DVD±RW)
Cores
Accessories
1GB PC3-10600 DDR3 Non-ECC UDIMM 57Y4389
2GB PC3-10600 DDR3 Non-ECC UDIMM 57Y4390
250GB SATA 3.0Gb/s Disk (7200 rpm) 41N3015
500GB SATA 3.0Gb/s Disk (7200 rpm) 43R1990
1TB SATA 3.0Gb/s Disk (7200 rpm) 45J7918
Blu-ray™ Burner SATA 1.5Gb/s 45K1675
NVIDIA Quadro 256MB NVS 295 45K1669
NVIDIA Quadro 512MB NVS 450 57Y4398
More accessories on O-CAD sheet
Other accessories at lenovo.com/accessories
• Faster, more effi cient architecture with the latest Intel® workstation technology
• True workstation-level performance at incredibly low price point
• High Reliability with Independent Software Vendors (ISV) certifi ed applications and ECC memory support
• This small and medium business (SMB) model is part of the US TopSeller
™ Program
• This model has a 3-year limited warranty
1
• This system is Microsoft
®
Offi ce 2010 Product Key Ready (O10PKR)
Pre-conf
RAID
②
optical
disk
⑤
③
Diskette
or Media
reader
