What to do if Lenovo Monitor screen is blank and power indicator is amber?
If your Lenovo Monitor screen is blank and the power indicator shows amber, the monitor might be in Standby or Suspend mode. To restore operation, press any key on the keyboard or move the mouse. You may also want to check the Power options settings on your computer.
Why is my Lenovo ThinkVision P49w-30 power indicator not lit?
If the power indicator is not lit and there is no image on your Lenovo Monitor, ensure the power cord is properly connected and the power switch is on. Also, verify that the outlet has power. Try using another power cord and electrical outlet to rule out those issues. Power on the monitor.
How to fix 'Out of Range' message on Lenovo ThinkVision P49w-30 Monitor?
If the words 'Out of Range' appear on your Lenovo Monitor screen and the power indicator is flashing white, it means that the system is set to a display mode not supported by the monitor. If you're replacing an older monitor, reconnect it and adjust the display mode to the specified range for your new monitor. If you are using a Windows system, restart the system in safe mode and select a supported display mode. If these options do not work, contact the Customer Support Centre.
How to improve image quality on Lenovo ThinkVision P49w-30 Monitor?
If the image quality on your Lenovo Monitor is unacceptable, first ensure the video signal cable is firmly plugged into both the system and the monitor. If the issue persists, the color settings may be incorrect; select another color setting from the OSD menu. Also, perform automatic image setup.
How to fix blurry image on Lenovo Monitor?
If you observe fuzzy lines in text or a blurry image, or horizontal or vertical lines through the image on your Lenovo Monitor, adjust the resolution settings on your system to match the native resolution for this monitor: 5120x1440 at 60 Hz. Also, perform automatic image setup. When working in the native resolution, you may find additional improvements by adjusting the Dots Per Inch (DPI) setting on your system.
What to do if Lenovo Monitor power indicator is amber but no image?
If the power indicator on your Lenovo Monitor is amber but there is no image, ensure the video signal cable is properly connected to both the system and the monitor. Additionally, check the brightness and contrast settings on the OSD menu and adjust them if they are at the lowest setting.
Why are pixels discolored on my Lenovo Monitor?
The appearance of one or more discolored pixels is a characteristic of LCD technology and not necessarily a defect. If there are more than five pixels missing, contact the Support Center.
General| HD type | DQHD |
|---|---|
| Color depth | 10 bit |
| Color gamut | 98 % |
| Pixel pitch | 0.234 x 0.234 mm |
| Pixel density | 109 ppi |
| Response time | 6 ms |
| Backlight type | W-LED |
| Display diagonal | 49 \ |
| Anti-glare screen | Yes |
| Display resolution | 5120 x 1440 pixels |
| Display technology | LED |
| Native aspect ratio | 32:9 |
| Maximum refresh rate | 60 Hz |
| Response time (fast) | 4 ms |
| Screen curvature rating | 3800R |
| Viewable size, vertical | 337 mm |
| Contrast ratio (dynamic) | 3000000:1 |
| Contrast ratio (typical) | 2000:1 |
| Display number of colors | 1.07 billion colors |
| Viewable size, horizontal | 1198.1 mm |
| Display brightness (typical) | 350 cd/m² |
| USB hub version | 3.2 Gen 1 (3.1 Gen 1) |
| DisplayPort version | 1.4 |
| Headphone connectivity | 3.5 mm |
| USB Power Delivery up to | 100 W |
| USB Type-A downstream ports quantity | 4 |
| RMS rated power | 10 W |
| NVIDIA G-SYNC | - |
| Compatible operating systems | Windows 10, Windows 11 |
| AC input voltage | 100 - 240 V |
| Power supply type | Internal |
| AC input frequency | 50/60 Hz |
| Power consumption (max) | 265 W |
| Power consumption (standby) | 0.5 W |
| Power consumption (typical) | 58 W |
| Tilt angle range | -5 - 23.5 ° |
| Cable lock slot type | Kensington |
| Panel mounting interface | 100 x 100, 100 x 200 mm |
| Color name | Raven Black |
| Certification | ENERGY STAR® Certified, TCO 9.0, TCO edge 2.0, EPEAT™ Gold, RoHS Eyesafe® Display 2.0, TÜV Low Blue Light (Hardware solution), TÜV Rheinland® Eye Comfort |
| Product color | Black |
| Package depth | 282 mm |
| Package width | 1310 mm |
| Package height | 525 mm |
| Package weight | 23300 g |
| Cables included | AC, DisplayPort, Thunderbolt, USB Type-A to USB Type-B |
| DisplayPort cable length | 1.8 m |
Weight and Dimensions| Bezel width (side) | 2.1 mm |
|---|---|
| Depth (with stand) | 253.9 mm |
| Width (with stand) | 1215.1 mm |
| Height (with stand) | 576.3 mm |
| Weight (with stand) | 15800 g |
| Bezel width (bottom) | 19.7 mm |
| Depth (without stand) | 110.4 mm |
| Height (without stand) | 370.1 mm |
| Weight (without stand) | 11100 g |
Essential safety precautions for using the monitor.
List of items included in the product package.
Description of monitor features, adjustments, controls, and setup steps.
Instructions for using the built-in KVM switch feature.
Guide to using OSD controls for image quality adjustments.
Information on supported display modes and power saving features.
Recommendations for cleaning, detaching stand, and wall mounting.
Detailed technical specifications of the monitor.
Solutions for common problems and steps for driver installation.
Details on warranty, service contacts, and important notices.
