4. Reinstall the removed parts. To complete the replacement, see “Completing the parts replacement” on
page 55.
Replacing the storage drive
Attention: Do not open your computer or attempt any repairs before reading the Important Product
Information Guide.
Replacing the 3.5-inch storage drive
1. Remove the computer cover. See “Removing the computer cover” on page 14.
2. Remove the front bezel. See “Replacing the front bezel” on page 15.
3. Pivot the drive bay assembly upward. See “Pivoting the drive bay assembly upward and downward” on
page 18.
4. Disconnect the signal cable and the power cable from the 3.5-inch storage drive.
5. Refer to the following to replace the 3.5-inch storage drive.
• 3.5-inch primary storage drive
Figure 17. Removing the 3.5-inch primary storage drive
Chapter 4. Replacing hardware 19
