Lenovo Yoga 9i Hardware Maintenance Manual

Touchpen
Remove the lower case
Make sure the following FRU (or CRU) has been removed.
“Remove the lower case” on page 29
Step 1. Place the computer upside down on a flat surface.
Step 2. Peel off the rubber foot from the right end and the left end. Then, remove the rubber foot.
Figure 4. Remove rubber foot
Step 3. Remove nine screws and then remove the lower case.
Figure 5. Remove nine screws and remove the lower case
Chapter 4. Removing a FRU or CRU 29

Lenovo Yoga 9i Specifications

General

Graphics	Intel Iris Xe Graphics
Operating System	Windows 11 Home
Wireless	Wi-Fi 6E, Bluetooth 5.2
RAM	16GB LPDDR5
Storage	1TB PCIe SSD
Weight	Starting at 1.4 kg (3.09 lbs)
Ports	Headphone / mic combo
Color	Oatmeal, Storm Grey
Display	14" 4K UHD (3840 x 2160) IPS, Touchscreen, 400 nits
Audio	Bowers & Wilkins speakers
