Lenovo Yoga 9i Hardware Maintenance Manual

Pen holder
Remove the power board and power board cable
Make sure the following FRU (CRU) has been removed.
“Remove the touchpen” on page 28
“Remove the lower case” on page 29
“Remove the battery pack” on page 30
“Remove the pen holder” on page 40
Step 1. Remove one screw and remove the power board and power board cable.
Figure 24. Remove one screw and remove power board and power board cable
Screw specifications
Number of screws
M2 x L3 1
Go to
https://support.lenovo.com/partslookup to look up the Lenovo part numbers of the following
replacement part:
Power board
Power board cable
Remove the system board
Make sure the following FRU (or CRU) has been removed.
“Remove the touchpen” on page 28
“Remove the lower case” on page 29
“Remove the battery pack” on page 30
“Remove the solid-state drive” on page 34
“Remove the solid-state drive thermalpad” on page 35
42
Yoga 9i (14″, 5) Hardware Maintenance Manual
