Lenovo Yoga 9i Hardware Maintenance Manual

Go to https://support.lenovo.com/partslookup to look up the Lenovo part numbers of the following
replacement part:
System board
Remove the antenna
Make sure the following FRU (or CRU) has been removed.
“Remove the touchpen” on page 28
“Remove the lower case” on page 29
“Remove the battery pack” on page 30
“Remove the solid-state drive” on page 34
“Remove the thermal module” on page 37
“Remove the system board” on page 42
Step 1. Remove eight screws and remove the antenna.
Figure 27. Remove the antenna
Screw specifications
Number of screws
M1.6 x L2.9 8
Go to
https://support.lenovo.com/partslookup to look up the Lenovo part numbers of the following
replacement part:
Antenna
Remove the upper case
Make sure the following FRU (CRU) has been removed.
“Remove the touchpen” on page 28
“Remove the lower case” on page 29
44
Yoga 9i (14″, 5) Hardware Maintenance Manual

Lenovo Yoga 9i Specifications

General

Graphics	Intel Iris Xe Graphics
Operating System	Windows 11 Home
Wireless	Wi-Fi 6E, Bluetooth 5.2
RAM	16GB LPDDR5
Storage	1TB PCIe SSD
Weight	Starting at 1.4 kg (3.09 lbs)
Ports	Headphone / mic combo
Color	Oatmeal, Storm Grey
Display	14" 4K UHD (3840 x 2160) IPS, Touchscreen, 400 nits
Audio	Bowers & Wilkins speakers
