Lenovo Yoga 9i Hardware Maintenance Manual

Figure 20. Remove one screw and the fingerprint sensor bracket
Screw specifications Number of screws
M2 x L2 1
Step 3. Remove the fingerprint sensor.
Figure 21. Remove the fingerprint sensor
Go to https://support.lenovo.com/partslookup to look up the Lenovo part numbers of the following
replacement part:
Fingerprint sensor and bracket
Remove the pen holder
Make sure the following FRU (or CRU) has been removed.
40
Yoga 9i (14″, 5) Hardware Maintenance Manual

Lenovo Yoga 9i Specifications

General

Graphics	Intel Iris Xe Graphics
Operating System	Windows 11 Home
Wireless	Wi-Fi 6E, Bluetooth 5.2
RAM	16GB LPDDR5
Storage	1TB PCIe SSD
Weight	Starting at 1.4 kg (3.09 lbs)
Ports	Headphone / mic combo
Color	Oatmeal, Storm Grey
Display	14" 4K UHD (3840 x 2160) IPS, Touchscreen, 400 nits
Audio	Bowers & Wilkins speakers
