10
UL_Warn_3200C_EN
Lenze ¯ MA_3200_C ¯ 8.0
Approval accoding to UL
Underwriter Laboratories (UL), UL 508 and CSA C22.2 No. 142−M1987 (UL File Number
E236341)
Ratings
ƒ Input 24 V DC, max. 1.7 A
ƒ Max. surrounding air temperature:
– 3221C: 55 °C, vertical or horizontal mounting
– 3231 C / 3241 C / 3251 C:
45 °C, vertical (upright) mounting
50 °C, horizontal mounting
J Warnings!
Field Wiring Markings
Wiring terminal: Voltage supply (24 V DC)
ƒ Use copper wire only.
ƒ AWG 18 ... 12 (0.82 ... 3.3 mm
2
)
ƒ Torque 5 ... 7 lb−in (0.5 ... 0.6 Nm)
Wiring terminal: CAPS pack connection (only for 3241 C)
ƒ Use copper wire only.
ƒ AWG 18 ... 14 (0.82 ... 2.1 mm
2
)
ƒ Torque 2 lb−in (0.2 Nm)
Device
ƒ These devices are open type programmable controllers, provided with
housing for use in pollution degree 2 and controlled environment only.
ƒ Use this device only in the manner described in this manual. If the
equipment is used in a manner not specified by the manufacturer, the
protection provided by the equipment may be impaired.
Fieldbus interfaces / Optional filedbus module (MC−Card)
ƒ Use only together with appropriate cable connectors, provided with screws
for securement and secure connector to avoid loosening.
