Lenze 8400 StateLine C - Page 101

Mechanical installation
Standard devices in a power range of 0.25 ... 3 kW
Assembly in push−through technique (thermal separation)
5
l
101
EDS84ASC552 EN 8.1
TopLine
8400GG105g
Fig. 5−10 Dimensions for mounting
a e d
1
d
2
d
3
d
4
c c
1
c
2
c
3
i j
11
j
21
[kW] [mm] [kg]
E84AVTCD2512xXx
0.25
75 221 8.5 12.5 110 105 12 6 6 90 0 > 95 > 95 2.1
E84AVTCD371xxXx
0.37
E84AVTCD551xxXx
0.55
E84AVTCD751xxXx
0.75
E84AVTCD112xxXx
1.1
109 274 12.5 12.5 135 135 12 6 6 125 0 > 95 > 95 3.7
E84AVTCD152xxXx
1.5
E84AVTCD222xxXx
2.2
E84AVTCD2512xBx
0.25
75 221 8.5 12.5 110 105 12 6 6 90 0 > 95 > 95 2.2
E84AVTCD371xxBx
0.37
E84AVTCD551xxBx
0.55
E84AVTCD751xxBx
0.75
E84AVTCD112xxBx
1.1
109 274 12.5 12.5 135 135 12 6 6 125 0 > 95 > 95 3.8
E84AVTCD152xxBx
1.5
E84AVTCD222xxBx
2.2
