Lenze 8400 StateLine C - Page 124

Mechanical installation
Standard devices in the power range 3 ... 22 kW
Assembly in push−through technique (thermal separation)
5
l
124
EDS84ASC552 EN 8.1
StateLine, HighLine
8400GG107e
Fig. 5−29 Device dimensions
h b t h
1
h
2
b
1
t
1
t
3
g
1
g
2
[kW] [mm]
E84AVxxD7524xXx
7.5
325 174 141 378 426 140 128 64 6 5
E84AVxxD1134xXx
11
E84AVxxD1534xXx
15
E84AVxxD7524xBx
7.5
325 174 161 378 426 140 148 64 6 5
E84AVxxD1134xBx
11
E84AVxxD1534xBx
15
