Mechanical installation
Standard devices in the power range 3 ... 22 kW
Mounting in "cold plate" technique
5
l
134
EDS84ASC552 EN 8.1
StateLine, HighLine
8400GG107a
Fig. 5−38 Dimensions for mounting
d
1
d
2
d
3
d
4
d
5
c c
1
c
2
c
3
c
4
i j
11
j
21
[kW] [mm] [kg]
E84AVxxC7524xXx
7.5
9 9 120 120 120 15 7 7 80 80 0 > 95 > 95 3.6
E84AVxxC1134xXx
11
E84AVxxC1534xXx
15
E84AVxxC1834xXx
18.5
8.5 8.5 130 130 130 15 5.5 5.5 110 110 0 > 95 > 95 9.3
E84AVxxC2234xXx
22
E84AVxxC7524xBx
7.5
9 9 120 120 120 15 7 7 80 80 0 > 95 > 95 3.7
E84AVxxC1134xBx
11
E84AVxxC1534xBx
15
E84AVxxC1834xBx
18.5
8.5 8.5 130 130 130 15 5.5 5.5 110 110 0 > 95 > 95 9.4
E84AVxxC2234xBx
22
