Free connection of analog signals
Free configuration of analog outputs
10
Function library
10.12
10.12.2
L
10.12-6
EDS82EV903-1.0-11/2002
Code IMPORTANTPossible settings
No. SelectionLenzeName
C0419
v
(cont.)
Possible an alog signals for C0419
Selection 9 ... 25 correspond to the digital
functions of the re lay output K1 (C0008) or
the digital o utput A1 (C0117):
LOW = 0 V/0 mA/4 mA/ 0 kHz
HIGH = 10 V/20 mA/10 kHz
^
10.12-4
9 Ready for operation (DCTRL1-RDY)
10 TRIP fault message (DCTRL1-TRIP)
11 Motor is running (DCTRL1-RUN)
12 Motor is running / CW rotation (DCTRL1-RUN-CW)
13 Motor is running / CCW rotation
(DCTRL1-RUN-CCW)
14 Output frequency = 0 (DCTRL1-NOUT=0)
15 Frequency setpoint reached
(DCTRL1-RFG1=NOUT)
16 Value has fallen below frequency t hresho ld Q
min
(f < C0017) (PCTRL1-QMIN)
LOW active
17 I
max
limit reached (MCTRL1-IMAX)
C0014 = - 5- : Torque setpoint reached
18 Overtemperature (ϑ
max
-5°C)
(DCTRL1-OH-WARN)
19 TRIP or Q
min
or pulse inhibit (IMP) active
(DCTRL1-TRIP-QMIN-IMP)
20 PTC warning (DCTRL1-PTC-WARN)
21 Apparent motor current < current threshold
(DCTRL1-IMOT<ILIM)
Belt monitoring
Apparent motor current = C0054
22 Apparent motor current < current threshold and
output frequenc y > frequency threshold Q
min
(DCTRL1-(IMOT<ILIM)-QMIN)
Current t hreshold = C0156
Frequency threshold Q
min
= C0017
23 Apparent motor current < current threshold and
RFG 1: Input = output
(DCTRL1-(IMOT<ILIM)-RFG-I= 0)
24 Warning motor phase failure
(DCTRL1-LP1-WARN)
25 Minimum output frequency reached (f ≤ C0010)
(PCTRL1-NMIN)
LOW active
