Lenze E82MV251_2B

Function library
Parameter set management
7−93
L EDB82MV752 EN 5.2
) Note!
l Do not remove keypad as long as the parameters are being transmitted! If the
keypad is removed during transmission, the controller indicates the errors "Prx"
or "PT5".
l A detailed description of the keypads can be found in the "Parameter setting"
chapter.
Restoring the delivery status
1. Attach keypad.
2. Inhibit controller with  or via terminal (X3/28 = LOW).
3. Set the correct selection number in C0002 from the "Restore delivery status" category and
confirm with .
– E.g. C0002 = 1: Parameter set 1 of the controller is overwritten with Lenze setting.
Parameter set transfer from the controller to the keypad
1. Attach keypad.
2. Inhibit controller with  or via terminal (X3/28 = LOW).
3. Set C0002 = 20 or 50 or 80, confirm with .
Parameter set transfer from the keypad to the controller
1. Attach keypad.
2. Inhibit controller with  or via terminal (X3/28 = LOW).
3. Set the correct selection number In C0002 from the "Parameter set transfer with keypad"
category and confirm with .
– E.g. C0002 = 10: All parameter sets of the controller are overwritten with the settings in the
keypad.
– E.g. C0002 = 11: Parameter set 1 of the controller is overwritten with the settings in the
keypad.
Saving your own basic setting
1. Attach keypad.
2. Parameter set 1 must be active!
3. Inhibit controller with  or via terminal (X3/28 = LOW).
4. Set parameter in parameter set 1.
5. Set C0003 = 3 and confirm with .
6. Set C0002 = 9 and confirm with . The own basic setting is saved.
7. Set C0003 = 1 and confirm with .
Copying your own basic setting into the parameter sets
1. Attach keypad.
2. Inhibit controller with  or via terminal (X3/28 = LOW).
3. Set the correct selection number in C0002 from the "Loading/saving you own basic setting"
category and confirm with .
– E.g. C0002 = 5: Parameter set 1 is overwritten with your own basic setting.
– E.g. C0002 = 8: Parameter set 4 is overwritten with your own basic setting.
