Commissioning
Important controller codes
6

107
EDK82MV752 DE/EN/FR 7.2
IMPORTANTPossible settingsCode
SelectionLenzeNameNo.
C0002*
&
uSEr
(Contin.)
Transferring
parameter sets
with the keypad
Keypad ð PAR1 (+ FPAR1)
Overwrite selected parameter set
and, if required FPAR1, with the
corresponding data of the keypad
71 with function module application I/O,
INTERBUS, PROFIBUS−DP, LECOM−B,
DeviceNet/CANopen
11
with all other function modules
Keypad ð PAR2 (+ FPAR1)
72 with function module application I/O,
INTERBUS, PROFIBUS−DP, LECOM−B,
DeviceNet/CANopen
12
with all other function modules
Keypad ð PAR3 (+ FPAR1)
73 with function module application I/O,
INTERBUS, PROFIBUS−DP, LECOM−B,
DeviceNet/CANopen
13
with all other function modules
Keypad ð PAR4 (+ FPAR1)
74 with function module application I/O,
INTERBUS, PROFIBUS−DP, LECOM−B,
DeviceNet/CANopen
14
with all other function modules
Controller ð keypad
Copy all available parameter sets
(PAR1 ... PAR4, if required FPAR1) into
the keypad
80 with function module application I/O,
INTERBUS, PROFIBUS−DP, LECOM−B,
DeviceNet/CANopen
20
with all other function modules
Keypad ð function module
Only overwrite the module−specific
parameter set FPAR1 with the data of
the keypad
40 only with function module INTERBUS,
PROFIBUS−DP, LECOM−B,
DeviceNet/CANopen
Function module ð keypad
Only copy the module−specific
parameter set FPAR1 into the keypad
50 only with function module INTERBUS,
PROFIBUS−DP, LECOM−B,
DeviceNet/CANopen
C0002*
&
uSEr
(Contin.)
Saving your own
basic setting
9 PAR1 ð own basic setting For the parameters of the controller
you can save an own basic setting
(e.g. the delivery status of your
machine):
1. Ensure that parameter set 1 is
active
2. Inhibit controller
3. Set C0003 = 3, confirm with #
4. Set C0002 = 9, confirm with #,
the own basic setting is saved
5. Set C0003 = 1, confirm with #
6. Enable the controller
C0002*
&
uSEr
(Contin.)
Loading/copying
the own basic
setting
By using this function you can also
just copy PAR1 into the parameter
sets PAR2 ... PAR4
5 own basic setting ð PAR1
Restore own basic setting in the
parameter set selected
6 own basic setting ð PAR2
7 own basic setting ð PAR3
8 own basic setting ð PAR4
