Lenze E82MV752 - Page 108

Commissioning
Important controller codes
6

108
EDK82MV752 DE/EN/FR 7.2
IMPORTANTPossible settingsCode
SelectionLenzeNameNo.
C0003*
#
Saving
parameters
non−volatilely
1
0 Do not save parameters in the EEPROM Data loss after mains switch−off
1 Always save parameters in the EEPROM l Active after every mains
connection
l Cyclic alteration of parameters via
bus module is not permissible
3 Save your own basic setting in the EEPROM Afterwards save parameter set 1 as
own basic setting with C0002 = 9
C0007
#
uSEr
Fixed
configuration
digital inputs
Change of C0007 is copied into the
corresponding subcode of C0410.
Free configuration in C0410 sets
C0007 = 255!
0
E4 E3 E2 E1
l CW/CCW = clockwise
rotation/counter−clockwise
rotation
l DCB = DC injection brake
l QSP = quickstop
l PAR = change over parameter set
(PAR1 ó PAR2)
– PAR1 = LOW, PAR2 = HIGH
– The terminal in PAR1 and PAR2
has to be assigned with the
"PAR" function.
– Only use configurations with
"PAR" if C0988 = 0
l TRIP−Set = external error
0
CW/CCW DCB JOG2/3 JOG1/3
1
CW/CCW PAR JOG2/3 JOG1/3
2
CW/CCW QSP JOG2/3 JOG1/3
3
CW/CCW PAR DCB JOG1/3
4
CW/CCW QSP PAR JOG1/3
5
CW/CCW DCB TRIP−Set JOG1/3
6
CW/CCW PAR TRIP−Set JOG1/3
7
CW/CCW PAR DCB TRIP−Set
8
CW/CCW QSP PAR TRIP−Set
9
CW/CCW QSP TRIP−Set JOG1/3
10
CW/CCW TRIP−Set UP DOWN
C0007
#
uSEr
(Contin.)
E4 E3 E2 E1
l Selection of fixed
setpoints
JOG1/3 JOG2/3
LOW LOW
HIGH LOW
LOW HIGH
HIGH HIGH
Active
C0046
JOG1
JOG2
JOG3
11
CW/CCW DCB UP DOWN
12
CW/CCW PAR UP DOWN
13
CW/CCW QSP UP DOWN
14
CCW/QSP CW/QSP DCB JOG1/3
15
CCW/QSP CW/QSP PAR JOG1/3
16
CCW/QSP CW/QSP JOG2/3 JOG1/3
17
CCW/QSP CW/QSP PAR DCB
18
CCW/QSP CW/QSP PAR TRIP−Set
19
CCW/QSP CW/QSP DCB TRIP−Set
C0007
#
uSEr
(Contin.)
E4 E3 E2 E1
l UP/DOWN = motor potentiometer
functions
l H/Re = manual/remote
change−over
l PCTRL1−I−OFF = switch off I
component of process controller
l DFIN1−ON = digital frequency
input 0 ... 10 kHz
l PCTRL1−OFF = switch off process
controller
20
CCW/QSP CW/QSP TRIP−Set JOG1/3
21
CCW/QSP CW/QSP UP DOWN
22
CCW/QSP CW/QSP UP JOG1/3
23
H/Re CW/CCW UP DOWN
24
H/Re PAR UP DOWN
25
H/Re DCB UP DOWN
26
H/Re JOG1/3 UP DOWN
27
H/Re TRIP−Set UP DOWN
28
JOG2/3 JOG1/3
PCTRL1−I−OFF
DFIN1−ON
29
JOG2/3 DCB
PCTRL1−I−OFF
DFIN1−ON
30
JOG2/3 QSP
PCTRL1−I−OFF
DFIN1−ON
