Commissioning
Important controller codes
6

109
EDK82MV752 DE/EN/FR 7.2
IMPORTANTPossible settingsCode
SelectionLenzeNameNo.
C0007
#
uSEr
(Contin.)
E4 E3 E2 E1
31
DCB QSP
PCTRL1−I−OFF
DFIN1−ON
32
TRIP−Set QSP
PCTRL1−I−OFF
DFIN1−ON
33
QSP PAR
PCTRL1−OFF
DFIN1−ON
34
CW/QSP CCW/QSP
PCTRL1−I−OFF
DFIN1−ON
35
JOG2/3 JOG1/3 PAR DFIN1−ON
36
DCB QSP PAR DFIN1−ON
37
JOG1/3 QSP PAR DFIN1−ON
38
JOG1/3 PAR TRIP−Set DFIN1−ON
39
JOG2/3 JOG1/3 TRIP−Set DFIN1−ON
40
JOG1/3 QSP TRIP−Set DFIN1−ON
C0007
#
uSEr
(Contin.)
E4 E3 E2 E1
41
JOG1/3 DCB TRIP−Set DFIN1−ON
42
QSP DCB TRIP−Set DFIN1−ON
43
CW/CCW QSP TRIP−Set DFIN1−ON
44
UP DOWN PAR DFIN1−ON
45
CW/CCW QSP PAR DFIN1−ON
46
H/Re PAR QSP JOG1/3
47
CW/QSP CCW/QSP H/Re JOG1/3
48
PCTRL1−OFF
DCB
PCTRL1−I−OFF
DFIN1−ON
49
PCTRL1−OFF
JOG1/3 QSP DFIN1−ON
50
PCTRL1−OFF
JOG1/3
PCTRL1−I−OFF
DFIN1−ON
51
DCB PAR
PCTRL1−I−OFF
DFIN1−ON
255 Free configuration in C0410 Read only
Do not change C0007 since settings
in C0410 may get lost
C0010
uSEr
Minimum
output
frequency
0.00 0.00
à 14.5 Hz
{0.02 Hz} 650.00
l C0010 not effective in the case of
bipolar setpoint selection (−10 V ...
+ 10 V)
l C0010 only limits the analog input
1
l In the case of a max. output
frequency > 50 Hz the switching
threshold of the auto DCB in
C0019 has to be increased.
l From software 3.5: If
C0010 > C0011, the drive does not
start when controller enable is set.
à Speed setting range 1 : 6 for Lenze
geared motors: For operation with
Lenze geared motors has to be set
necessarily.
C0011
uSEr
Maximum
output
frequency
50.00 7.50
à 87 Hz
{0.02 Hz} 650.00
C0012
uSEr
Acceleration
time main
setpoint
5.00 0.00 {0.02 s} 1300.00 Reference: frequency change 0 Hz ...
C0011
l Additional setpoint ðC0220
l Acceleration times that can be
activated via digital signals ð
C0101
C0013
uSEr
Deceleration
time main
setpoint
5.00 0.00 {0.02 s} 1300.00 Reference: frequency change C0011...
0 Hz
l Additional setpoint ðC0221
l Deceleration times that can be
activated via digital signals ð
C0103
