Lenze EL 9800 - 2.3 Safety instructions for the installation according to UL

Safety instructions
Safety instructions for the installation according to UL
2

13
BA_ELx8xx EN 3.0
2.3 Safety instructions for the installation according to UL
Original − English
Approval
Underwriter Laboratories (UL), UL508 and CSA C22.2 No. 142−M1987, (UL File Number
E236341)
Ratings
ƒ Input 24 V DC, 65 W
ƒ Max. Ambient Temperature 40 °C
– EL6xx, EL1xxx, EL5xxx, EL9xxx only
ƒ Max. Surrounding Temperature 50 °C
– EL8xx, EL2xxx, EL7xxx only
ƒ Optional communication ratings:
– RS232−Connection: max. 3 A
– USB−Connection: max. 1 A
– PS/2−Connection: max. 1 A
– LAN−Connection: Standard ISDN or RJ45
ƒ Environmental ratings: If these devices are mounted into a door or front cover of an
enclosure: Type 1 enclosure.
 Warnings!
Field Wiring Markings
Wiring Terminal MSTB 2,5/3−STF−5,08:
ƒ Use Copper Wire only.
ƒ AWG 18 ... AWG 12 (0.82 mm
2
... 3.3 mm
2
)
ƒ Torque 5...7 lb−in (0.5 ... 0.6 Nm)
Power supply
ƒ Must be used as isolating source.
ƒ Rated data: 24 VDC, 4 A max.
Battery
ƒ Replace Battery with any from the list below, Part No. CR 2450 only. Use of
another battery may present a risk of fire or explosion.
Recommended CR2450 (R/C, BBVC2) types:
Renata Part.no. CR2450N, Sony Corp. part no. CR2450B, Toshiba part no.
CR2450, Varta part no. CR2450, Matsushita part no. CR2450
ƒ Battery may explode if mistreated. Do not recharge, disassemble, dispose of
in fire or heat above 100 °C (212 °F).
ƒ Dispose of used battery according to the regulation of recycling or waste.
