Technical data
Electrical data
4
l
47
BA_DVIUSB DE/EN 5.0
Operating conditions
Mounting conditions
Mounting place
DVI/USB TX4 In the control cabinet, near the IPC
IPC <−> DVI/USB TX4 cable length:
l Standard cable (scope of supply): max. 2 m
l Lenze DVI/USB cable set: 5 m
DVI/USB RX4 MP system: to the back of the device
CS system: into the mounting frame of the device
DVI/USB TX4 <−> RX4 cable length: 10 ... 35 m
Ambient conditions
Climatic
Storage
−25 ... +70 °C
Transport −25 ... +70 °C
Operation 0 ... +50 °C
Relative humidity 10 ... 95 %, non−condensing
Site altitude < 3000 m amsl
4.2 Electrical data
Rated data
Operating voltage +24 V DC (18 ... 30 V)
With MP 9000 DVI/CS 9000 DVI and a transmission
path > 20 m:
+24 V DC (20 ... 30 V)
Input current DVI/USB TX
without optional supply of the display
unit
max. 0.2 A (standby < 50 mA)
with optional supply of the display unit max. 2 A
Output current DVI/USB RX
(optional 24V supply of the display unit)
max. 1.8 A
Transmittable graphics resolution VGA (640 x 480 pixels) to SXGA (1280 x 1024 pixels)
USB connection USB 1.1 and 2.0, max. 12 Mbit/s (full speed)
