Lenze ERBM R Series

Technische Daten
Mechanische Daten
4
EDKRBM390R DE/EN/FR/ES/IT 3.1
17

H1_Daten−FN_Toleranz +30mm
Mechanische Daten
ERBM82−003
a b* c1 c2 d2 d3* e
[mm]
ERBM020R150W
20.6
337
12.8 7.9 7.5
317
60
ERBM039R120W 267 247
ERBM100R100W 235 220
40
ERBM180R050W 175 160
ERBM390R100W 235 220
g1 h1 h2 k1 k2 s**
[mm] [kg]
ERBM020R150W
4.3
>30 >30 >200 >100
700
1.10
ERBM039R120W 0.91
ERBM100R100W
500
0.37
ERBM180R050W 0.28
ERBM390R100W 0.37
*
Toleranz ±1 mm
**
Toleranz +30mm
