6 Installation électrique
Opérations de montage
EDKRBM390R DE/EN/FR/ES/IT 3.1
60
H1_E_INST−Mech Installation Aufkleber
Variante 2 : avec rallongement des câbles
R
B
<5m
< 0.1 m
PE
PES
PES
ERBMXXX014
Connexion HF (collier de blindage) via connexion avec PE
par surface importante
Câbles torsadés
Opérations de montage
ERBM82−004
