Page #36 background image
4 Technical data
Rated data
EDKRBM390R DE/EN/FR/ES/IT 3.1
36
H1_Daten−FN_Toleranz +30mm
Rated data
Electrical data
R
B
P
d
Q
B
U
max
[W]
[W] [kWs] [V
DC
]
ERBM020R150W 20
150 13
800
ERBM039R120W 39 120 6
ERBM100R100W 100
100 15
400
ERBM180R050W 180 50 7.5
ERBM390R100W 390 100 15 800
R
B
Resistance
P
d
Permanent power
Q
B
Heat quantity
U
max
Max. operating voltage
Temperatures
T
nom
T
TK
T
max
[°C]
On the surface 200 300 500
On the clearance
edge
*)
90 100 120
T
nom
Maximum temperature for rated data
T
TK
Temperature at which the thermal contact is activated
T
max
Maximum temperature in the case of improper use
*) Measured for air as the ambient medium (small coefficient of
thermal conductivity); if materials which heat up are located
at the clearance edge (greater coefficient of thermal
conductivity), the temperature continues to rise.
