3.5.12 BCD decade switch (BCD)
3−120
l
EDSVS9332P−EXT DE 2.0
Overview of the codes for the evaluation of the read data and for the selection of the target code.
Function BCD1 BCD2 BCD3
Output signal (DIS) C1700/1 C1710/1 C1720/1
BCD result of the read data (DIS) C1700/2 C1710/2 C1720/2
Target code C1701 C1711 C1721
Subcode of the target code C1702 C1712 C1722
Numerator (evaluation of the result) C1703 C1713 C1723
Denominator (evaluation of the result) C1704 C1714 C1724
Offset (evaluation of the result) C1705 C1715 C1725
Function
l BCD decade switch
l Data inputs
l Signal processing
l "CANCEL" function
l "RESET" function
l BCD decade switch
l Complete BCD reading
l BCD mode
3.5.12.1 Data inputs
Evaluation of the read data:
BCDx−Datax
MSB ... LSB
BCD ABSOLUTE VALUE BCD−SIGN
0000 0
(+)
0001 1
0010 2
0011 3
0100 4
0101 5
0110 6
0111 7
1000 8
(−)
1001 9
1010 CANCEL CANCEL
1011 RESET RESET
1100
BCD error BCD error
1101
1110
1111
