3.5.40 Fixed setpoints (FIXSET)
3−203
l
EDSVS9332P−EXT DE 2.0
3.5.40.1 Release of the FIXSET1 setpoints
Number of the fixed setpoints required Number of inputs to be assigned
1 at least 1
1 ... 3 at least 2
4 ... 7 at least 3
8 ... 15 4
System for decoding the binary input signals:
Output signal
FIXSET1−OUT =
1st input
FIXSET1−IN1
2nd input
FIXSET1−IN2
3rd input
FIXSET1−IN3
4th input
FIXSET1−IN4
FIXSET1−Ain 0 0 0 0
C0560/1 1 0 0 0
C0560/2 0 1 0 0
C0560/3 1 1 0 0
C0560/4 0 0 1 0
C0560/5 1 0 1 0
C0560/6 0 1 1 0
C0560/7 1 1 1 0
C0560/8 0 0 0 1
C0560/9 1 0 0 1
C0560/10 0 1 0 1
C0560/11 1 1 0 1
C0560/12 0 0 1 1
C0560/13 1 0 1 1
C0560/14 0 1 1 1
C0560/15 1 1 1 1
