Function library
Function blocks
3.5.48 Speed setpoint conditioning (NSET)
3−227
l
EDSVS9332P−EXT DE 2.0
3.5.48.2 JOG setpoints
l Are fixed values which are stored in the memory.
l JOG values can be called from the memory via the inputs NSET−JOG*x.
l The inputs NSET−JOG*x are binary coded so that 15 JOG values can be called.
l The decoding for enabling the JOG values (called from the memory) is carried out according to
the following table:
Output signal 1st input
NSET−JOG*1
2nd input
NSET−JOG*2
3rd input
NSET−JOG*4
4th input
NSET−JOG*8
NSET−N 0 0 0 0
JOG 1 1 0 0 0
JOG 2 0 1 0 0
JOG 3 1 1 0 0
JOG 4 0 0 1 0
JOG 5 1 0 1 0
JOG 6 0 1 1 0
JOG 7 1 1 1 0
JOG 8 0 0 0 1
JOG 9 1 0 0 1
JOG 10 0 1 0 1
JOG 11 1 1 0 1
JOG 12 0 0 1 1
JOG 13 1 0 1 1
JOG 14 0 1 1 1
JOG 15 1 1 1 1
l When all inputs are assigned with 0, the input NSET−N is active.
l The number of inputs that must be assigned depends on the required number of JOG values.
Four inputs and thus 15 possible selections are available. A digital signal source is assigned
via C0787 and the corresponding subcode.
Number of required JOG setpoints Number of inputs to be assigned
1 at least 1
1 ... 3 at least 2
4 ... 7 at least 3
8 ... 15 4
