Lenze EVS9323EP User Manual

Function library
Function blocks
3.5.48 Speed setpoint conditioning (NSET)
3−226
l
EDSVS9332P−EXT DE 2.0
Signal Source Note
Name Type DIS DIS format CFG List Lenze
NSET−N O C0046 dec [%] C0780 1 50 Intended for main setpoint, other signals
are permissible
NSET−NADD O C0047 dec [%] C0782 1 5650 Intended for additional setpoint, other
signals are permissible
NSET−JOG*1 d C0799/4 bin C0787/1 2 53
Selection and control of overriding "fixed
setpoints" for the main setpoint
NSET−JOG*2 d C0799/5 bin C0787/2 2 1000
NSET−JOG*4 d C0799/6 bin C0787/3 2 1000
NSET−JOG*8 d C0799/7 bin C0787/4 2 1000
NSET−TI*1 d C0799/8 bin C0788/1 2 1000
Selection and control of alternative
acceleration and deceleration times for the
main setpoint
NSET−TI*2 d C0799/9 bin C0788/2 2 1000
NSET−TI*4 d C0799/10 bin C0788/3 2 1000
NSET−TI*8 d C0799/11 bin C0788/4 2 1000
NSET−N−INV d C0799/1 bin C0781 2 10251 Control of the signal inversion for the main
setpoint
NSET−NADD−INV d C0799/2 bin C0783 2 1000 Control of the signal inversion for the
additional setpoint
NSET−RFG−0 d C0799/12 bin C0789 2 1000 The main setpoint integrator is led to zero
via the current T
i
times.
NSET−RFG−STOP d C0799/13 bin C0790 2 1000 Keeping (freezing) of the main setpoint
integrator to its actual value.
NSET−CINH−VAL O C0798/1 dec [%] C0784 1 5001 Here, the signal is applied which is to be
accepted by the main setpoint integrator
when the controller is inhibited
NSET−SET O C0798/2 dec [%] C0785 1 5000 Here, the signal is applied which is to be
accepted by the main setpoint integrator
when the NSET−LOAD input is set
NSET−LOAD d C0799/3 bin C0786 2 5001 Control of both ramp function generators in
special situations, e.g. QSP
NSET−OUT O − − − − − −
NSET−RFG−I=0 d − − − − − −
Function
l Main setpoint path
l JOG setpoints
l Setpoint inversion
l S ramp
3.5.48.1 Main setpoint path
l The signals in the main setpoint path are limited to the value range ±199.99 %.
l The signal at input NSET−N is led via the function JOG selection.
l The JOG function has priority over the setpoint input NSET−N. This means a selected JOG
value deactivates the input. The subsequent signal conditioning the JOG value instead.
