Lenze EVS9323EP

Function library
Function blocks
3.5.53 Phase integrator (PHINT)
3−243
l
EDSVS9332P−EXT DE 2.0
3.5.53.2 Scaling of PHINTx−OUT
Mathematic description of PHINTx−OUT:
PHINTx–OUT[inc] + PHINTx–IN[rpm] @ t[s] @ 65536[incńUmdr.]
t = integration time
Example:
You want to determine the count of the integrator with a certain speed at the input and a certain
integration time.
l Given values:
– PHINTx−IN = 1000 rpm
– t = 10 s
– Start value of the integrator = 0
l Solution:
– Conversion of PHINTx−IN:
1000rpm +
1000rev.
60s
– Calculation of PHINTx−OUT:
PHINTx * OUT +
1000rev.
60s
 @ 10s @
65536inc
rev.
 + 10922666inc
