Function library
Function blocks
3.5.63 Teach−in in programming (TEACH)
3−269
l
EDSVS9332P−EXT DE 2.0
Function
l The FB accepts a value (e.g. actual position) at TEACH1−L−IN.
l A LOW HIGH edge at TEACH1−SET transmits the value TEACH1−L−IN to the selected table
position in VTPOS.
l A LOW−HIGH edge at TEACH−NEXT selects the next table position.
– 30 table positions (VTPOS−No 71 ... VTPOS−No 100) are available.
– The number of the selected table position can be displayed via C1403.
– TEACH1−CNT transmits the number of the table position as analog signal.
l TEACH1−CLR = HIGH resets all values in the table positions to zero and selects
simultaneously the table position VTPOS−No 71.
l An analog signal at TEACH1−LDVAL selects directly a table position (VTPOS−No).
– Signal values < 71 = interpreted as VTPOS−No 71.
– Signal values > 100 = interpreted as VTPOS−No 100.
– TEACH1−LOAD = HIGH selects the position.
l If the levels are applied at the same time to the digital inputs, the following priority is valid:
– TEACH1−CLR (1)
– TEACH1−LOAD (2)
– TEACH1−NEXT (3)
– TEACH1−SET (4)
Tip!
Save the target positions permanently using C0003.
