Function library
Function blocks
3.5.66 Variable table Piece number (VTPCS)
3−276
l
EDSVS9332P−EXT DE 2.0
Function
A total of 34 table positions are available.
l Enter fixed values under C1304.
– 30 table positions (VTPCS−No1 ... VTPCS−No30) are available.
– Subcodes (C1304/1 ... C1304/30) define the table position number.
l Enter variable values in VTPCS−INx.
– 4 table positions (VTPCS−No31 ... VTPCS−No34) are available.
– Signal input via function blocks.
– The values must be transmitted to the table positions before the corresponding program set
starts and accesses these values.
l C1386 displays the values on the table positions.
– Select table position (C1386/1 ... C1386/34) with subcode.
l For signals with percentage standardization at VTPCS−INx the conversion is performed
according the the formula:
VTPCS–INx[inc] + VTPCS–INx[%] @
16384[inc]
100%
Tip!
Entries into the processing table are necessary only if the FB inputs and outputs are used.
