Application examples
4.1 Example 1: Dosing system
4−5
l
EDSVS9332P−EXT DE 2.0
Travel profiles
Time Description
1, 6 Container has almost reached the target position
· Brake feed
2, 7 Container in target position
· Start filling (observe dead time)
5, 10 Filling completed
· Start feed, filled container leaves positioning sensor, empty container is positioned
Dosing drive B
PS Time Description
01 0 − 2 Waiting for input POS−PFI 32, signal at X5/E4 (H level). The feed drive starts the dosing drive if the container is
positioned.
2 − 5 Filling according to program set parameters
5 Start feed (drive A): switch POS−PFO1, X5/A4; L level
· Jump to program set 1 (PS01)
Transport drive FEED A
PS Time Description
01 2 − 5 Wait for input POS−PFI = 0 level
5 − 6 Feed until TP(E4) responds
6 − 7 Cover residual path and stop
7 Start dosing drive PFO 01 = H: A4 = High, then jump to PS01
02 Is required to complete the program.
