Function library
Table of function blocks
3−15
l
EDSVS9332P−EXT DE 2.0
Function block Used in basic configurationCPU time
[ms]
DescriptionFunction block
2600022000200001000
CPU time
[ms]
Description
CONVDA1 Digital−analog converter 1  3−150
38
CONVDA2 Digital−analog converter 2
CONVDA3 Digital−analog converter 3
CONVPHA1 Phase analog converter 1  3−153
6
CONVPHA2 Phase analog converter 2
CONVPHA3 Phase analog converter 3
CONVPHPH2 Phase converter 2  3−155 80 ·
CURVE1 Characteristic function  3−156 15 ·
DB1 Dead band  3−159 7
DCTRL Device control  3−160 −
DFIN Digital frequency input  3−164 5 ·
DFOUT Digital frequency output  3−167 35 · · · ·
DFRFG1 Digital frequency ramp function generator  3−171 40
DFSET Digital frequency processing  3−177 85
DIGDEL1 Binary delay element 1  3−182
9
DIGDEL2 Binary delay element 2
DIGIN Input terminals X5/E1…X5/E5  3−185 −
DIGOUT Output terminals X5/A1…X5/A4  3−186 −
DISA Free analog display code  3−187 1
DISPH Free phase display code  3−189 1
DT1 Differential element  3−190 12
FCNT1 Free piece counter, block 1  3−191
11
FCNT2 Free piece counter, block 2
FCNT3 Free piece counter, block 3
FDO Free digital outputs  3−193 −
FEVAN1 Free analog input variable  3−195
4
FEVAN2 Free analog input variable
FEVAN3 Free analog input variable
FEVAN4 Free analog input variable
FEVAN5 Free analog input variable
FEVAN6 Free analog input variable
FIXSET1 Fixed setpoints  3−202 9
FLIP1 D−flipflop 1  3−204
6
FLIP2 D−flipflop 2
LIM1 Limiter  3−207 5
MCTRL Servo control  3−208 −
MPOT1 Motor potentiometer  3−220 20
NOT1 Logic NOT, block1  3−223
4
· · ·
NOT2 Logic NOT, block2 ·
NOT3 Logic NOT, block3 ·
NOT4 Logic NOT, block4
NOT5 Logic NOT, block5
NSET Speed setpoint conditioning  3−225 70 ·
OR1 Logic OR, block1  3−230
6
·
OR2 Logic OR, block2 ·
OR3 Logic OR, block3
OR4 Logic OR, block4
OR5 Logic OR, block5
OSC Oscilloscope function  3−233 70
PCTRL1 Process controller  3−237 58
PHDIV1 Conversion  3−240 8
PHINT1 Phase integrator  3−241 7
POS Positioning control  3−19 330 · · ·
PT1−1 1st order delay element  3−244 8
R/L/Q QSP / setpoint inversion  3−245 8 ·
RFG1 Ramp function generator  3−246 16
S&H1 Sample and Hold  3−248 4
