Function block library
7-61
SHB9300CRV EN 2.0
Byte 1, 2, 3 and 4
The meaning of these user data can be selected among different signal types. Depending on the
requirement, up to two analog signals, 32 digital signals of the function block FDO or a phasesignal
can be selected.Mixed forms are also possible.
Byte 5 and 6
Here, the analog signal configured at the input CAN-OUT3.W3 is mapped.
Byte 7 and 8
Here, the analog signal configured at the input CAN-OUT3.W4 is mapped.
