Function block library
7-57
 SHB9300CRV EN 2.0
Byte 1, 2, 3 and 4
The meaning of these user data can be selected among different signal types. Depending on the
requirement, these data can be evaluated as up to 2 analog signals, 32 digital signals or one phase
signal.Mixed forms are also possible.
Byte 5 and 6
form the signal to CAN-IN3.W3.
Byte 7 and 8
form the signal to CAN-IN3.W4.
