Function block library
7-56

SHB9300CRV EN 2.0
Signal Source Note
Name Type DIS DIS format CFG List Lenze
CAN-IN3.W1 a C0866/8 dec [%] - - - +16384 = +100 %
CAN-IN3.W2 a C0866/9 dec [%] - - - +16384 = +100 %
CAN-IN3.W3 a C0866/10 dec [%] - - - +16384 = +100 %
CAN-IN3.W4 a C0866/11 dec [%] - - - +16384 = +100 %
CAN-IN3.D1 ph C0867/3 dec [inc] - - - 65536 = 1 revolution
CAN-IN3.B0 d C0863/5 hex - - -
CAN-IN3.B1 d C0863/5 hex - - -
CAN-IN3.B2 d C0863/5 hex - - -
CAN-IN3.B3 d C0863/5 hex - - -
CAN-IN3.B4 d C0863/5 hex - - -
CAN-IN3.B5 d C0863/5 hex - - -
CAN-IN3.B6 d C0863/5 hex - - -
CAN-IN3.B7 d C0863/5 hex - - -
CAN-IN3.B8 d C0863/5 hex - - -
CAN-IN3.B9 d C0863/5 hex - - -
CAN-IN3.B10 d C0863/5 hex - - -
CAN-IN3.B11 d C0863/5 hex - - -
CAN-IN3.B12 d C0863/5 hex - - -
CAN-IN3.B13 d C0863/5 hex - - -
CAN-IN3.B14 d C0863/5 hex - - -
CAN-IN3.B15 d C0863/5 hex - - -
CAN-IN3.B16 d C0863/6 hex - - -
CAN-IN3.B17 d C0863/6 hex - - -
CAN-IN3.B18 d C0863/6 hex - - -
CAN-IN3.B19 d C0863/6 hex - - -
CAN-IN3.B20 d C0863/6 hex - - -
CAN-IN3.B21 d C0863/6 hex - - -
CAN-IN3.B22 d C0863/6 hex - - -
CAN-IN3.B23 d C0863/6 hex - - -
CAN-IN3.B24 d C0863/6 hex - - -
CAN-IN3.B25 d C0863/6 hex - - -
CAN-IN3.B26 d C0863/6 hex - - -
CAN-IN3.B27 d C0863/6 hex - - -
CAN-IN3.B28 d C0863/6 hex - - -
CAN-IN3.B29 d C0863/6 hex - - -
CAN-IN3.B30 d C0863/6 hex - - -
CAN-IN3.B31 d C0863/6 hex - - -
Function
The input signals of the 8 byte user data of this CAN object are converted into corresponding signal
types. The signals can be used via further function blocks.
