Lenze EVS9326-EK User Manual

Configuration
7-318

SHB9300CRV EN 2.0
Code ImportantPossible settingsLCDCode Important
SelectionLenze
LCD
S&H
[C0570] CFG: IN 1000 FIXED 0 % @ Selection list 1 Configuration analog input of S&H1
[C0571] CFG: LOAD 1000 FIXED 0 @ Selection list 2 Digital input of S&H1
C0572 DIS: C0570 -199.99 {0.01 %} 199.99 Display of C0570
C0573 DIS: C0571 Display of C0571
SELPH
C1660 DIS: act.sel. 0 0{1}8Display of the actual selection
[C1661] CFG: SELPH1-SE-
LECT
1000 FIXED0% @ Selection list 1
[C1662]
1
..
8
CFG: SELPH1-IN1
...
CFG: SELPH1-IN8
1000 FIXED0INC @ Selection list 3
C1663 DIS: C1661 0 -32768 {1} 32767 Display of C1661
C1664 DIS: C1662 0 -2147483648 {1 inc} 147483647 Display of C1662
C1665 DIS: act.sel. 0 0{1}8Display of the actual selection
[C1666] CFG: SELPH2-SE-
LECT
1000 FIXED0% @ Selection list 1
[C1667]
1
..
8
CFG: SELPH2-IN1
...
CFG: SELPH2IN8
1000 FIXED0INC @ Selection list 3
C1668 DIS: C1666 0 -32768 {1} 32767 Display of C1666
C1669 DIS: C1667 0 -2147483648 {1 inc} 2147483647 Display of C1667
SPC
[C1640] CFG: RESET 1000 FIXED0 @ Selection list 2
C1641
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
SP-value 1-1
SP-value 1-2
SP-value 2-1
SP-value 2-2
SP-value 3-1
SP-value 3-2
SP-value 4-1
SP-value 4-2
SP-value 5-1
SP-value 5-2
SP-value 6-1
SP-value 6-2
SP-value 7-1
SP-value 7-2
SP-value 8-1
SP-value 8-2
1 FCODE1476/x
FCODE1477/x
FCODE0474/x
VTPOSC-No.x
SPC1
SP-value 1-1: Switch point output STAUS-01
SP-value 1-2: Switch point output STAUS-01
...
...
SP-value 8-1: Switch point output STAUS-08
SP-value 8-2: Switch point output STAUS-08
[C1642] CFG: L-IN 1000 FIXED0INC @ Selection list 3
C1643 DIS: C1640 0 0{1}1Display of C1640
C1644 DIS: C1642 0 -1073741824 {1 inc} 1073741823 Display of C1642
C1645 SPC1 mode 0 0{1}10on/off
1 centre/range
[C1650] CFG: RESET 1000 FIXED0 @ Selection list 2
