Lenze EVS9326-EK User Manual

Configuration
7-319
 SHB9300CRV EN 2.0
Code ImportantPossible settingsLCDCode Important
SelectionLenze
LCD
C1651
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
SP-value 1-1
SP-value 1-2
SP-value 2-1
SP-value 2-2
SP-value 3-1
SP-value 3-2
SP-value 4-1
SP-value 4-2
SP-value 5-1
SP-value 5-2
SP-value 6-1
SP-value 6-2
SP-value 7-1
SP-value 7-2
SP-value 8-1
SP-value 8-2
1 FCODE 1476/1 @ Selection list 1 SPC2
SP-value 1-1: Switch point output STAUS-01
SP-value 1-2: Switch point output STAUS-01
...
...
SP-value 8-1: Switch point output STAUS-08
SP-value 8-2: Switch point output STAUS-08
[C1652] CFG: L-IN 1000 FIXED0INC @ Selection list 3
C1653 DIS: C1650 0 0{1}1Display of C1640
C1654 DIS: C1652 0 -1073741824 {1 inc} 1073741823 Display of C1652
C1655 SPC2 mode 0 0{1}10on/off
1 centre/range
C1657
1
..
4
Death time
..
Death time
0 -30000 {1 ms} 30000 SP2 dead time
C1658 Hysteresis 0 -32767 {1 inc} 32767 SP2 hysteresis
C1659 Filter 1 0/1/2/4/8/16 Filters
0 Filter off
1 Filter 1 ms
2 Filter 2 ms
4 Filter 4 ms
8 Filter 8 ms
16 Filter 16 ms
SRFG
C1040 Accelaration 100.00 0.001 {0.001} 5000.000 Acceleration of SRFG1
C1041 Jolt 0.200 0.001 {0.001 s} 999.999 Adjust jolt of SRFG1
[C1042] CFG: IN 1000 FIXED0% @ Selection list 1 Configuration input of SRFG1
[C1043] CFG: SET 1000 FIXED0% @ Selection list 1 Configuration input of SRFG1
[C1044] CFG: LOAD 1000 FIXED0 @ Selection list 2 Digital input of SRFG1
C1045
1
2
DIS: C1042
DIS: C1043
-199.99 {0.01 %} 199.99 Display of
C1042
C1043
C1046 DIS: C1044 Display of C1044
STAT
C0150 DIS: Status word 0 {1} 65535 Status word when networked with automation interfa-
ces
l Binary interpretation indicates the bit states
[C0156]
1
2
3
4
5
6
7
CFG: STAT.B0
CFG: STAT.B2
CFG: STAT.B3
CFG: STAT.B4
CFG: STAT.B5
CFG: STAT.B14
CFG: STAT.B15
2000
5002
5003
5050
10650
505
500
@ Selection list 2
DCTRL-PAR*1-O
MCTRL-IMAX
MCTRL-MMAX
NSET-RFG I=O
CMP1-OUT
DCTRL-CW/CCW
DCTRL-RDY
Configuration of the free bits of the status
word
C0157 DIS: C0156 01Display of C0156
STATE-BUS
[C0440] CFG: STATE-BUS 1000 @ Selection list 2 Configuration state bus X5/ST
C0441 DIS: C0440 Display of C0440
