Configuration
7-323

SHB9300CRV EN 2.0
7.10 Selection list for signal connections
The signals must be connected by entering their numbers to configure the controller via thekeypad.
Selection list 1, analog output signals (
L
)
000050 AIN1-OUT 019500 FCODE-17 020101 CAN-IN1.W1
000055 AIN2-OUT 019502 FCODE-26/1 020102 CAN-IN1.W2
000100 DFSET-NOUT 019503 FCODE-26/2 020103 CAN-IN1.W3
001000 FIXED0% 019504 FCODE-27/1 020201 CAN-IN2.W1
001006 FIXED100% 019505 FCODE-27/2 020202 CAN-IN2.W2
001007 FIXED-100% 019506 FCODE-32 020203 CAN-IN2.W3
005000 MCTRL-NSET2 019507 FCODE-37 020204 CAN-IN2.W4
005001 MCTRL-NACT 019510 FCODE-108/1 020301 CAN-IN3.W1
005002 MCTRL-MSET2 019511 FCODE-108/2 020302 CAN-IN3.W2
005003 MCTRL-MACT 019512 FCODE-109/1 020303 CAN-IN3.W3
005005 MCTRL-DCVOLT 019513 FCODE-109/2 020304 CAN-IN3.W4
005009 MCTRL-PHI-ACT 019515 FCODE-141 025101 AIF-IN.W1
005050 NSET-NOUT 019521 FCODE-472/1 025102 AIF-IN.W2
005100 MPOT1-OUT 019522 FCODE-472/2 025103 AIF-IN.W3
005150 PCTRL1-OUT 019523 FCODE-472/3
005200 REF-N-SET 019524 FCODE-472/4
005500 ARIT1-OUT 019525 FCODE-472/5
005505 ARIT2-OUT 019526 FCODE-472/6
005550 ADD1-OUT 019527 FCODE-472/7
005600 RFG1- OUT 019528 FCODE-472/8
005650 ASW1-OUT 019529 FCODE-472/9
005655 ASW2-OUT 019530 FCODE-472/10
005700 ANEG1-OUT 019531 FCODE-472/11
005705 ANEG2-OUT 019532 FCODE-472/12
005750 FIXSET1-OUT 019533 FCODE-472/13
005800 LIM1-OUT 019534 FCODE-472/14
005850 ABS1-OUT 019535 FCODE-472/15
005900 PT1-1-OUT 019536 FCODE-472/16
005950 DT1-1-OUT 019537 FCODE-472/17
006100 MFAIL-NOUT 019538 FCODE-472/18
006150 DB1-OUT 019539 FCODE-472/19
006200 CONV1-OUT 019540 FCODE-472/20
006205 CONV2-OUT 019551 FCODE-473/1
006210 CONV3-OUT 019552 FCODE-473/2
006215 CONV4-OUT 019553 FCODE-473/3
006230 CONVPHA1-OUT 019554 FCODE-473/4
006400 FCNT1-OUT 019555 FCODE-473/5
006300 S&H1-OUT 019556 FCODE-473/6
006350 CURVE1-OUT 019557 FCODE-473/7
010000 BRK-M-SET 019558 FCODE-473/8
013301 CDATA-ACTCAM 019559 FCODE-473/9
013302 CURVEC1-AOUT 019560 FCODE-473/10
013601 CSEL1-OUT
013351 CCTRL-NOUT
013352 CCTL-MOUT
013701 MSEL1-MVAL
013711 MSEL2-MVAL
