Configuration
7-322

SHB9300CRV EN 2.0
Code ImportantPossible settingsLCDCode Important
SelectionLenze
LCD
VTPOSC
[C1360]
1
2
3
4
5
6
7
8
9
10
CFG: IN1
CFG: IN2
CFG:IN3
CFG:IN4
CFG:IN5
CFG:IN6
CFG:IN7
CFG:IN8
CFG:IN9
CFG:IN10
1000 FIXED0INC @ Selection list 3
C1361 DIS: C1361 0 0/1 Display of C1361
WELD
C1444
1
2
3
4
5
CFG: XIN
CFG: LEN-O
CFG: LEN-C
CFG: LEN
CFG: TIME
1000 FIXED0INC @ Selection list 3
1. Input X position
2. Time of the closing phase
3. Time of the opening phase
4. Time of the cam profile
5. Welding time in ms (1 inc = 1 ms)
C1445 DIS: C1444 Display of C1444
YSET
C1350 Direction of rotation
of actual value
0 0{1}10CWrotation
1 CCW rotation
C1352 CFG: FACT 1000 FIXED0% @ Selection list 1 Stretching/compression factor:
+100% = no compression/stretching
> 100% = compression
< 100% = stretching
C1353 DIS: C1352 Display of C1352
C1354
1
2
CFG: RESET
CFG: SYNCH
1000 FIXED 0 @ Selection list 2 1: Reset of the -OFFS input
2: Clock pulse input for synchronous switching of the
stretching/compression factor
C1355 DIS: C1354 Display of C1354
C1356 CFG: OFFS 1000 FIXED0 INC @ Selection list 3 Offset value
C1357 DIS: C1356 Display of C1356
C1358
1
2
CFG: IN
CFG: IN-SYNCH
1000 FIXEDPHI-0 @ Selection list 4 Input in rpm
C1359 DIS: C1358 Display of C1358
