1 Preface and general information
1.1 About these Operating Instructions
• The present Operating Instructions will assist you in connecting and commissioning the 93XX
servo inverter. They include safety notes which you must observe.
• All persons working on and with the controller must have the operating instructions available
and must observe the information and notes relevant for their work.
• The Operating Instructions must always be in a complete and perfectly readable state.
• Further information on the controller can be obtained from the Catalog and the Manual.
1.1.1 Terminology used
Term In the following text used for
93XX Any type of servo inverter (types 9321 ... 9332)
Controller The 93XX servo
Drive system Drive system with 93XX servos and other Lenze drive components
1.1.2 What is new / what has changed ?
Material no. Edition Important Contents
391489 01/1997 1st edition
395638 05/1997 substitues
391489
• Chapter 3.3
• Chapter 4.1.2
• Chapter 6.2.2
403496 06/1998 substitues
395638
• Chapter 1 - 4 revised
• Acceleration drive mode
• Oscilloscope function
414796 05/2000 substitues
403469
• Chapter 3.3.5: Mains filter
• Chapter 4.2.4: Mains types/mains conditions
• Chapter 4.2.9ff: Motor temperature monitoring
• Chapter 11.3: Code list
414796 10/2000 substitues
05/2000
1.2 Packing list
Packing list Important
• 1 servo inverter type 93XX
• 1 book of Operating Instructions
• 1 accessory kit (bits and pieces for mechanical and
electrical installation)
After receipt of the delivery, check immediately whether the items delivered match
the accompanying papers. Lenze does not accept any liability for deficiencies
claimed subsequently.
Claim
• visible transport damage immediately to the forwarder.
• visible deficiencies/incompleteness immediately to your Lenze representative.
