9.8.2 Basic sengs
IP basic sengs
The basic IP sengs are required to let the engineering soware access the network nodes
(PLC, inverter) directly via Ethernet.
The PC with the engineering soware must be in the same network as the devices to be con-
gured.
First, congure the PC so that this condion is fullled.
The required steps are described by the example of the operang system Microso
®
Win-
dows
®
7.
How to dene the IP basic sengs:
1.Call the "Network and sharing center" under "Control panel".
2.Select "Change adapter sengs" (observe administrator rights!).
3.Select the network to be congured (double-click), e. g.:
The network nodes (PLC, inverter) must be connected to the network.
The status dialog box of the network is opened.
4.Click "Properes".
The properes dialog box of the network is opened.
5.Select "Internet protocol version 4 (TCP/IPv4)" and click "Properes".
The properes dialog box of the "Internet protocol version 4 (TCP/IPv4)" is opened.
6.Enter the IP address, the subnet mask and, if required, the gateway address under "Use the
following addresses".
7.Click "OK".
The IP basic sengs are now completed.
Set IP address
The two rotary encoder switches at the front of the device serve to set the IP address in terms
of hardware.
Seng Addressing
0x00 IP address via the parameter 0x23B1:001 (P510.01).
0x01 ... 0xFF Seng of the 4th byte of the IP address via the rotary encoder switch.
192.168.124.[seng]
Example: Seng for the value 52
(3 × 16) + (4 × 1) = 52
x16 x1
The value set via the rotary encoder switches is used when the mains is switched on or aer a
network restart with 0x23B0 (P508.00) = 1. A changed value during operaon will only
become valid aer the network has been restarted.
•
0x23B3 (P509.00) shows the switch seng at the last mains connecon.
•
0x23B2:001 (P511.01) shows the acve IP address.
Time-To-Live (TTL)
The TTL value (8-bit value) limits the number of routers a sent package passes on the way to
its target.
•
0x23A1:006 (P510.06): Time-to-live value (TTL)
Conguring the network
Modbus TCP
Basic sengs
349
