9 Maintenance/repair
M aintenance operations
M otor plug connection assignm ent
9.3.4 M o tor plug connection assignm ent
This m otor-plug assignment is a rough selection of possible mechanical com binations.
1
Note!
W hen m aking yo ur selection, the m otor data and perm issible currents of
the cables according to the system cable system manual m ust be
observed.
Further inform ation is provided in the system cables system manual at:
www.Lenze.de ^ Dow nload ^Tech n ical docum entation ^ Accessories
(product range) ^ System manual (filter: Content type)
Connector Connectable cross-section of the motor cable
EWS0001 / EWS1001 1.0 mm2, 1.5 mm2, 2.5 mm2
EWS0012 / EWS1012 2.5 mm2, 4.0 mm2
EWS0013 / EWS1013 6.0 mm2, 10.0 mm2, 16.0 mm2
9.3.5 Power connection fo r plug-in connector at the cable end
Asynchronous servo m otors
Motor type Plug size * Screw plug SpeedTec
Spare part
designation
Coding in the system
cable type code
Spare part
designation
Coding in the system
cable type code
MCA 10I40- ... S00
13I34- ... Fx0
13I41- ... S00
14L16- . . Fx0
14L20- . . S00
14L35- . . Fx0 M23 EWS0001 M01 EWS1001 M04
14L41- . . S00
17N17- ... Fx0
17N23- ... S00
17N35- ... Fx0
17N41- ... S00
19S17- .. Fx0
M40 EWS0012 M02 EWS1012 M05
19S23- ... S00
19S35- ... Fx0 M40
EWS0012 M02 EWS1012 M05
EWS0013 M03 EWS1013 M06
19S42- ... S00
M40
EWS0012 M02 EWS1012 M05
20X14- .. Fx0 EWS0013 M03 EWS1013 M06
20X29- .. Fxx M40 EWS0013 M03 EWS1013 M06
21X17- .. Fx0 M40
EWS0012 M02 EWS1012 M05
EWS0013 M03 EWS1013 M06
21X25- .. S00
M40
EWS0012 M02 EWS1012 M05
21X35- .. Fx0 EWS0013 M03 EWS1013 M06
21X42- .. S00
M40
EWS0012 M02 EWS1012 M05
MQA 20 EWS0013 M03 EWS1013 M06
EN
* At times, older documents also stated plug sizes of 1.0 (M23) and 1.5 (M40).
42
Lenze • BA 33.0006 • 3.0
