Lenze MCS 06F41 - Inverter Power Supply 400 V, Forced Ventilated Motors

Inverter power supply 400 V, forced venlated motors
Motor MCS 12H34- MCS 12H14- MCS 12L39- MCS 12L17- MCS 12D35- MCS 12D17-
Standsll torque M
0
Nm 12.8 12.8 19.0 19.0 7.50 7.50
Rated torque M
rated
Nm 10.5 12.0 14.0 17.0 6.00 7.00
Max. torque M
max
Nm 29.0 29.0 56.4 56.4 17.7 17.7
Rated speed n
rated
rpm 3375 1350 3900 1650 3525 1650
Max. speed n
max
rpm 6000 6000 6000 6000 6000 6000
Rated power P
rated
kW 3.7 1.7 5.7 2.9 2.2 1.2
Standsll current I
0
A 8.50 4.60 14.4 7.20 6.40 3.20
Rated current I
rated
A 7.50 4.10 11.7 6.70 5.60 3.00
Max. current I
max
A 24.0 12.0 57.0 28.0 20.0 10.0
Rated voltage V
rated
V 320 310 295 300 300 330
Rated frequency f
rated
Hz 225 90 260 110 235 110
Moment of inera J kgcm² 7.30 7.30 10.6 10.6 4.00 4.00
Eciency η 0.86 0.8 0.94 0.9 0.85 0.75
Torque constant Kt
0 150
°C
Nm/A 1.51 2.78 1.32 2.64 1.17 2.34
Voltage constant KE
LL 150
°C
V/
(1000/
min)
84.58 169.15 72.94 145.69 67.07 133.95
Stator terminal resistance R
UV 20
°C
Ω 1.4 5.8 0.6 2.2 4.4 17.4
Stator terminal resistance R
UV 150
°C
Ω 2.11 8.741 0.904 3.315 6.631 26.222
Stator inductance L mH 10.5 42.1 5.45 21.8 13.0 52.2
Weight m kg 12.2 12.2 15.3 15.3 9.1 9.1
Technical data
Rated data
Inverter power supply 400 V, forced venlated motors
