Mechanical installaon
Important notes
•
Install the product according to the informaon in the chapter "Standards and operang
condions".
4Standards and operang condions ^ 36
•
The technical data and the data regarding the supply condions can be found on the
nameplate and in this documentaon.
•
Ambient media − especially chemically aggressive ones − may damage sha sealing rings,
lacquers and plascs.
•
Lenze oers special surface and corrosion protecon in this case.
Preparaon
•
Protect sha sealing rings from contact with solvents.
•
Remove protecon covers from shas.
•
Thoroughly remove ancorrosion agents from the sha and from ange faces.
•
Draw the transmission elements onto the output sha only by using the centering thread.
•
Align the output sha and transmission elements exactly to avoid tensions.
•
Mount belt pulleys, sprockets, or gear wheels as close as possible to the sha shoulder in
order to keep the bending load of the sha and the bearing forces at a minimum level.
•
Tighten all screw connecons with the specied torques and secure them with standard
screw locking adhesive.
•
Check paint for damage and repair professionally.
Thread M3 M4 M5 M6 M8 M10 M12 M16 M20 M24 M27 M30
Strength Tightening torque Nm ±10 %
8.8 Nm 1.3 3.0 5.9 10.1 24.6 48 84 206 415 714 1050 1428
10.9 Nm 1.9 4.6 8.6 14.9 36.1 71 123 302 592 1017 1496 2033
Installaon
•
The mounng surfaces must be plane, torsionally rigid and free from vibraons.
•
The mounng areas must be suited to absorb the forces and torques generated during
operaon.
•
Ensure an unhindered venlaon.
•
For versions with a fan, keep a minimum distance of 10 % from the outside diameter of the
fan cover in intake direcon.
Dimensions
Dimensions are contained in the conguraon document.
