Lenze MCS 06I41 - 230 V Self-Ventilated Motor Data (Part 3)

Motor MCS 09L41L MCS 12H15L MCS 12L20L MCS 12D41L MCS 12D20L MCS 12H30L
Standsll torque M
0
Nm 7.50 11.4 15.0 6.40 6.40 11.4
Rated torque M
rated
Nm 4.50 10.0 13.5 4.30 5.50 8.00
Max. torque M
max
Nm 32.0 29.0 56.0 18.0 18.0 29.0
Rated speed n
rated
rpm 4050 1500 1950 4050 1950 3000
Max. speed n
max
rpm 7000 6000 6000 6000 6000 6000
Rated power P
rated
kW 1.9 1.6 2.8 1.8 1.1 2.5
Standsll current I
0
A 12.4 8.20 12.4 10.7 5.50 13.5
Rated current I
rated
A 8.40 7.60 11.8 8.80 5.20 10.5
Max. current I
max
A 64.0 24.0 57.0 40.0 20.0 39.0
Rated voltage V
rated
V 145 158 165 155 175 165
Rated frequency f
rated
Hz 270 100 130 270 130 200
Moment of inera J kgcm² 2.80 7.30 10.6 4.00 4.00 7.30
Eciency η 0.91 0.86 0.9 0.84 0.85 0.87
Torque constant Kt
0 150
°C
Nm/A 0.605 1.39 1.21 0.598 1.16 0.844
Voltage constant KE
LL 150
°C
V/
(1000/
min)
35.1 84.58 75.19 34.22 67.07 51.82
Stator terminal resistance R
UV 20
°C
Ω 0.44 1.41 0.548 0.55 2.2 0.489
Stator terminal resistance R
UV 150
°C
Ω 0.663 2.125 0.826 0.829 3.315 0.737
Stator inductance L mH 2.50 10.5 5.50 3.40 13.0 4.00
Weight m kg 8.50 10.2 13.3 7.10 7.10 10.2
Technical data
Rated data
Inverter power supply 230 V, self-venlated motors
50
