LEO ACm60 - Technical Data; Implementation Standards

Acquaer Ltd. H-4900, Fehérgyarmat, Szatmári út 11.
Technical Data
 Max. flow: 1600L/min
 Max. head: 110m
 Output power: 0.25~7.5kW
 Max. suction:8m
 Insulation class: IPX4
 Protection class: F
 Max. ambient temperature: +40℃
 Max. liquid temperature: +60℃
Type
ACm60
ACm75
ACm150
ACm150B2
Power
600 W / 0,8 HP
750 W / 1,0 HP
1500 W / 2,0 HP
1500 W / 2,0 HP
Inlet/outlet diameter
1” / 1”
1” / 1”
1,25” / 1”
2” / 2”
Qmax
5,4 m3/h
6,0 m3/h
8,4 m3/h
30 m3/h
Hmax
25 m
33 m
45,5 m
22 m
Max. Suction
8 m
8 m
8 m
8 m
Gross weight
11,5 kg
13,4 kg
22,8 kg
20,7 kg
Package
333x215x260mm
333x215x260mm
425x265x310mm
415x225x285mm
Implementation Standards
 IEC/EN 60335-1 Household and similar electrical appliances--safety
Part1: General requirements.
 IEC/EN 60335-2-41 Household and similar electrical appliances--
safety Part2-41: Particular requirements for pump.
 2006/95/EC Low voltage directive
