LEO APm75 - Model Description and Technical Data; Key Technical Specifications

Acquaer Ltd. H-4900, Fehérgyarmat, Szatmári út 11.
Model Description
Technical Data
 Max. flow: 90L/min
 Max. head: 100m
 Output power: 0.25~2.2kW
 Max. Suction: 8m
 Insulation class: IPX4
 Protection class: F
 Max. ambient temperature: +40℃
 Max. liquid temperature: +60℃
Type
APm37
APm75
Power
370 W / 0,5 HP
750 W / 1,0 HP
Inlet/outlet diameter
1” / 1”
1” / 1”
Qmax
2,4 m3/h
3,0 m3/h
Hmax
35 m
70 m
Max. Suction
8 m
8 m
Gross weight
5,5 kg
10,5 kg
Package
283x158x171mm
335x190x210mm
