Installation and maintenance
R448 & R448 V50
A.V.R.
4
3972 en - 02.2008 / d
LEROY-SOMER
1 - GENERAL INFORMATION
1.1 - Description
The A.V.R. R 448 V50 is delivered in a box
designed to be mounted on a panel with
suspension.
Connexions are made with «Faston»
connectors.
- Operating temperature: - 30°C to +70°C
- Storage temperature: - 55°C to + 85°C
- Shocks on the base: 9g for the 3 axis
- Vibrations: Less than 10Hz: 2mm half
peak amplitude
10Hz to 100Hz: 100mm/s, above 100Hz:
8g
1.2 - Identification
These 2 A.V.R.s have strictly identical
characteristics and dimensions, the
following details distinguish the V50:
- an adjuster dedicated to the alternator
LSA 50.2,
- the elimination of the ST6 jumper (A)
- a white serigraphy (B)
(blue for R 448),
- a label stipulating the type of alternator
(C).
A
R 448
R 448 V50
B
C
