Lesco 020092 - Rotary Spreader Parts List; Jet-Action Deflector Parts

Rotary Spreaders — Parts List
1
The Optional
Jet-Action Deflector
Part No. 060087
Parts List
Ref.LESCO No.
No. No. Description Used
70 061064 SS Handle..................... 1
71 061065 SS Bracket .................... 1
72 061066 Deflector ....................... 1
73 061053 SS Washer .................... 1
74 061052 SS Cotter Pin ................ 1
75 060036 Nylock Nut, 1/4-20 ........ 1
76 060057 Screw 1/4-20 x7/8 ......... 1
77 031851 Rubber Pad................... 1
Shutoff Assembly
Operating Lever
Rod Assembly
(Ref. 20)
70
77
71
72
72
76
73
74
